WILSONPRO 5143
WILSONPRO 5143

Targeted 5G coverage with four amplifier ports

GET A FREE CONSULTATION

Completely cover three bands

Four independently controlled amplifier paths connect to four indoor antenna ports to deliver complete indoor coverage with up to 21 dBm in uplink power and 18 dBm in downlink power per port, for a total of 24 dBm. The Enterprise 5143 completely covers three bands at once to allow carrier signal aggregation to improve data throughput.

test_benefits_photo

Ensure enhanced in-building cell signal with the WilsonPro 5143

4 amplification ports for maximum coverage

Four independently controlled indoor antenna ports deliver up to 8,000 sq. m. of indoor coverage, operating in either traditional Common Mode or Split Mode.

Secure remote connectivity and monitoring

Monitor the unit remotely and turn cell bands on and off as needed through the WilsonPro Cloud without the need for a hardline connection to keep your network secure.

Color LCD touch screen

The Enterprise 5143 system uses a color LCD touch screen to access amplifier performance and view amplifier configuration.

Extended Dynamic Range (XDR)

XDR allows the WilsonPro Enterprise 5143 system to make automatic, real-time adjustments so it never shuts down due to a strong outside signal.

Remote control via built-in modem

Built-in onboard software automatically controls the Enterprise 5143, ensuring reliable connectivity throughout large spaces and multi-story buildings. The amplifier will adjust its gain level up or down as required by the conditions of the immediate signal environment.

Future-proof connectivity

Future-proof connectivity

Leveraging open design, modularity, and proprietary technology, our exclusive Connected Architecture ensures DAS solutions can add new capabilities and scale to cover any sized building or campus without compromise. Discover how the Enterprise 5143 keeps up with ever changing signal environments.

LAUNCH SOLUTIONS TOUR

Technical Specs

Download the complete WilsonPro 5143 spec sheet

DOWNLOAD NOW
  • MODEL NUMBER
    510007
    FREQUENCIES
    Band 12100 MHz
    Band 31800 MHz
    Band 72600 MHz
    Band 8900 MHz
    MAX GAIN
    70 dB
    MAX UPLINK POWER
    21 dBm
    MAX DOWNLINK POWER
    18 dBm
    IMPEDANCE
    50 Ohm
    POWER
    110-240 VAC / 50-60 Hz / 30 W
    CONNECTORS
    N-Female
    AMPLIFIER DIMENSIONS
    19 x 12 x 2.5 in
    AMPLIFIER WEIGHT
    16.930 lbs
